SCHEDA DI RETE ZYXEL XGN100C-ZZ0101F 1P MULTIGIGABIT 1/2,5/5/10GB

Descrizione

SCHEDA DI RETE ZYXEL XGN100C-ZZ0101F 1P MULTIGIGABIT 1/2,5/5/10GB

System Specifications
Standard:
– IEEE 802.3an 10Gbps Ethernet
– IEEE 802.3bz 2.5Gbps/ 5Gbps Ethernet
– IEEE 802.3ab Gigabit Ethernet
– IEEE 802.3u Fast Ethernet
– IEEE 802.1az Energy Efficient Ethernet
– IEEE 802.1p Priority Queuing
Performance:
– Quality of Service
– Jumbo frame support up to 16 KB
Features:
– Compatibility with current network standards, including 10/5/2.5/1Gbps and 100Mbps
– Support Windows ® and Linux®
– Built-in Quality of Service (QoS) technology
Supported OS:
– Windows 7, 8, 8.1,10 (32/64-bit) or Server 2012
– Linux kernels 3.11, 3.2, 4.15, 4.2, or 4.44

Hardware Specifications
Interface:
– PCI Express Gen-3 (or2) x4 Host Bus Interface
– 1x 10 Gbps RJ-45 Ethernet port (Supported Speeds: 10 Gbps / 5 Gbps / 2.5 Gbps / 1 Gbps / 100 Mbps)
– Pre-installed with full height bracket, also includes low profile bracket
LED Indicator:
Speed:
– Green: 10G
– Amber: 5G/2.5G/1G/100M
Link/Activity:
– Green
– Steady: No data transmission
– Blink: Data transmission

Physical Specifications
Item dimensions (WxDxH): 82 x 68 x 18mm (3.22” x 2.67” x 0.7”)
Item weight: 78 g (0.17 lb.)
Packing dimensions (WxDxH): 170 x 137 x 30 mm (6.69” x 5.39” x 1.18”)
Packing weight: 178 g (0.39 lb.)

Environmental Specifications
Operating Environment:
– Temperature: 0°C to 40°C (32°F to 104°F)
– Humidity: 0% to 90% (Non-condensing)
Storage Environment:
– Temperature: -40°C to 85°C (-40°F to 185°F)
– Humidity: 0% to 90% (Non-condensing)

Certification
EMC: CE, FCC, EAC, BSMI, Class B

Package Contents
XGN100C
Quick Start Guide
Low profile bracket
