Descrizione
SWITCH 24P LAN GIGABIT HIKVISION DS-3E0524-E(B) 48GBPS 240 VAC 18W – UNMANAGED
Network Parameters
Port Number: 24 × Gigabit RJ45 ports
Port Type: RJ45 port, Full duplex, MDI/MDI-X adaptive
Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding Mode: Store-and-forward switching
MAC Address Table: 8 K
Internal Cache: 4.1 Mbits
Switching Capacity: 48 Gbps
Packet Forwarding Rate: 35.712 Mpps
General
Shell: Metal material, fan-free design
Net Weight: 1.6 kg (3.5 lb)
Gross Weight: 2.469 kg (5.44 lb)
Dimension (W × H × D): 335 mm × 44.5 mm × 175.8 mm (13.2” × 1.8” × 6.9”)
Operating Temperature: 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature: –40˚C to 85˚C (–40˚F to 185˚F)
Storage Humidity: 5% to 95% (no condensation)
Power Supply: 220 VAC， 50/60 Hz， Max. 0.7 A
Approval
EMC: FCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 14)
Safety: UL (UL 62368-1); CB/RCM (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2024)
Chemistry: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2013)
