SWITCH 5P LAN GIGABIT TP-LINK TL-SG105E EASY SMART IGMP SNOOPING,MTU/PORT/TAG-BASED VLAN QOS -GARANZIA A VITA

Descrizione

SWITCH 5P LAN GIGABIT TP-LINK TL-SG105E EASY SMART IGMP SNOOPING,MTU/PORT/TAG-BASED VLAN QOS -GARANZIA A VITA

CARATTERISTICHE HARDWARE
Standard e protocolli: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Interfaccia:
– 5 10/100/1000Mbps RJ45 Ports
– AUTO Negotiation/AUTO MDI/MDIX
Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
Numero ventole: Fanless
Alimentazione: 100-240VAC, 50/60Hz
Dimensioni ( L x P x A ): 3.9 * 3.9 *1.0 in. (100 * 98 *25 mm)
Max Power Consumption: 2.66W(220V/50Hz)
Max Heat Dissipation: 9.07BTU/h

PRESTAZIONI
Packet Forwarding Rate: 7.4Mpps
Tabella ARP: 2K
Buffer (pacchetti): 1.5Mb
Jumbo frame: 15KB

CARATTERISTICHE SOFTWARE
QoS (Quality of Service):
– Support Port-based/802.1p/DSCP priority 2
– Support 4 priority queues
– Rate Limit
– Storm Control
Funzionalità L2:
– IGMP Snooping V1/V2/V3
– Link Aggregation
– Port Mirroring
– Cable Diagnostics
– Loop Prevention
VLAN:
– Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
– MTU/Port/Tag VLAN
Metodo di trasmissione: Store-And-Forward

ALTRO
Certificazione: FCC, CE, RoHS
Contenuto della confezione:
– TL-SG105E
– Power Cord
– Installation Guide
– Resource CD
– Rubber Feet
Requisiti di sistema: Microsoft® Windows® for running Utility
Ambiente:
– Operating Temperature: 0℃~40℃ (32℉~104℉)
– Storage Temperature: -40℃~70℃ (-40℉~158℉)
– Operating Humidity: 10%~90% non-condensing
– Storage Humidity: 5%~90% non-condensing
