SWITCH 5P LAN GIGABIT UBIQUITI USW-FLEX-XG L2 4P 10GBE RJ45 + 1P GBE 802.3AT POE+ RJ45.

Descrizione

SWITCH 5P LAN GIGABIT UBIQUITI USW-FLEX-XG L2 4P 10GBE RJ45 + 1P GBE 802.3AT POE+ RJ45.

Mechanical
Dimensions: 135 x 185 x 32 mm (5.31 x 7.28 x 1.27″)
Weight: 1.2 kg (2.65 lb)
Enclosure Material: Polycarbonate

Hardware
Total Non-Blocking Throughput: 41 Gbps
Switching Capacity: 82 Gbps
Forwarding Rate: 61.012 Mpps

Max Power Consumption: 25W
Power Method:
– (1) 802.3at PoE, 50-57VDC, 25W
– (1) USB Type-C, 5VDC, 5A
Power Supply:
– 802.3at PoE (Pins 1, 2+/3, 6- or 4, 5+/7, 😎
– AC/DC Power Adapter, 5VDC, 5A, 1.5 m Cord (Included)
Supported Voltage Range: 90 to 264VAC (Adapter)

Management Interface: Ethernet In-Band
Networking Interfaces:
– (1) 10/100/1000 Mbps RJ45 Ethernet
– (4) 1/2.5/5/10 Gbps RJ45 Ethernet

Services: SMB Layer 2 Gigabit Ethernet Switch
ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV

Button: Factory Reset
Operating Temperature: -5 to 45° C (23 to 113° F)
Operating Humidity: 10 – 90% Noncondensing
Certifications: CE, FCC, IC

LEDs
System: (1) Power, Blue/White
– Flashing White: Bootup in Progress
– Flashing Blue: Firmware Upgrading
– Steady White: Factory Defaults, Awaiting Adoption
– Steady Blue: Device is Adopted
Ethernet: White: Link or Activity
