WIRELESS ACCESS POINT IN WALL UBIQUITI UNIFI UAP-AC-IW DUALBAND 2.4GHZ/300M 5GHZ/867M 802.11A/B/G/N/AC – 250 UTENTI

Descrizione

WIRELESS ACCESS POINT IN WALL UBIQUITI UNIFI UAP-AC-IW DUALBAND 2.4GHZ/300M 5GHZ/867M 802.11A/B/G/N/AC – 250 UTENTI

Mechanical
Dimensions: 139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01″)
Weight: 200 g (6.43 oz)

Hardware
Networking Interface: (3) GbE RJ45 Ports
Buttons: Reset
Power Method: PoE+ Supported
Power Supply: UniFi PoE Switch (Not Included)
PoE Out: 48V Pass-Through (Pins 1, 2+; 3, 6-)
Maximum Power Consumption: 7W
With PoE Passthrough: 19W
Maximum TX Power:
– 2.4 GHz: 20 dBm
– 5 GHz: 20 dBm
Antennas:
– (1) Dual-Band Antenna, Single-Polarity
– 2.4 GHz: 1 dBi
– 5 GHz: 2 dBi
Mounting: 1-Gang Electrical Wall Box (Not Included)
Operating Temperature: -10 to 50° C (14 to 122° F)
Operating Humidity: 5 to 95% Noncondensing
Certifications: CE, FCC, IC

Software
WiFi Standards: 802.11 a/b/g/n/r/k/v/ac
Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
BSSID: Up to 8 per Radio
VLAN: 802.1Q
Advanced QoS: Per-User Rate Limiting
Guest Traffic Isolation: Supported
Power Save: Supported
WMM: Voice, Video, Best Effort, and Background
Concurrent Clients: 250

Supported Data Rates (Mbps)
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5 Mbps to 300 Mbps (MCS0 -MCS15, HT 20/40)
802.11ac: 6.5 Mbps to 867 Mbps (MCS0 -MCS9 NSS1/2, VHT 20/40/80)
