WIRELESS ACCESS POINT UBIQUITI UNIFI UAP-AC-SHD SECURITY AND BLE HIGH DENSITY DUALBAND 2.4GHZ/5GHZ802.11A/B/G/N/AC/AC-WAVE2

Descrizione

WIRELESS ACCESS POINT UBIQUITI UNIFI UAP-AC-SHD SECURITY AND BLE HIGH DENSITY DUALBAND 2.4GHZ/5GHZ802.11A/B/G/N/AC/AC-WAVE2

Mechanical
Dimensions: 220 x 220 x 48.1 mm (8.66 x 8.66 x 1.89″)
Weight:
– Without Mounting Hardware: 700 g (1.54 lb)
– With Mounting Hardware: 830 g (1.83 lb)
Enclosure Characteristics: Outdoor UV Stabilized Plastic

Hardware
Networking Interface: (2) 10/100/1000 Ethernet Ports
Ports: (2) Ethernet RJ45, (1) USB Type C
Radios: 2.4 GHz, 5 GHz, Security
Max. Power Consumption: 20W
Supported Voltage Range: 44 – 57VDC
Power Method: PoE+
Power Supply: UniFi Switch (PoE Adapter)
Button: Reset
Antennas:
– 2.4 GHz: (2) Dual-Port, Dual-Polarity Antennas, 6 dBi each
– 5 GHz: (2) Dual-Port, Dual-Polarity Antennas, 6 dBi each
Max. TX Power:
– 2.4 GHz: 6-25 dBm
– 5 GHz: 6-25 dBm
MIMO:
– 2.4 GHz: 4 x 4
– 5 GHz: 4 x 4
Speeds:
– 2.4 GHz: 800 Mbps
– 5 GHz: 1.7 Gbps
Mounting: Wall/Ceiling (Kits Included)
Operating Temperature: -10 to 70° C (14 to 158° F)
Operating Humidity: 5 to 95% Noncondensing
Certifications: CE, FCC, IC

Software
WiFi Standards: 802.11 a/b/g/n/r/k/v/ac/ac-Wave2
Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w (PMF)
BSSID: Up to 8 per Radio
VLAN: 802.1Q
Advanced QoS: Per-User Rate Limiting
Guest Traffic Isolation: Supported
Power Save: Supported
Beamforming: Supported
WMM: Voice, Video, Best Effort, and Background
Concurrent Clients: 1000+

Supported Data Rates (Mbps)
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)
802.11ac: 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80)
