WIRELESS N ACCESS POINT 3550M CEILING MOUNT DUALBAND TP-LINK EAP660 HD WI-FI 6-1P ×2.5GBPS RJ45,802.3AT POE, MU-MIMO

Descrizione

WIRELESS N ACCESS POINT 3550M CEILING MOUNT DUALBAND TP-LINK EAP660 HD WI-FI 6-1P ×2.5GBPS RJ45,802.3AT POE, MU-MIMO

CARATTERISTICHE HARDWARE
Interfaccia: 1× 2.5 Gbps Ethernet Port (supports IEEE802.3at PoE)
Tasto: Reset
Alimentazione:
– 802.3at PoE
– 12 V DC
Consumo energetico:
– EU: 18.5 W
– US: 21.5 W
Dimensioni ( L x P x A ): 243 × 243 × 64 mm
Tipo di antenna: Internal Omni
– 2.4 GHz: 4× 4 dBi
– 5 GHz: 4× 5 dBi
Tipo di montaggio: Ceiling /Wall Mounting (Kits included)

CARATTERISTICHE WIRELESS
Standard wireless: IEEE 802.11ax/ac/n/g/b/a
Frequenza: 2.4 GHz and 5 GHz
Signal rate:
– 5 GHz: Up to 2402 Mbps
– 2.4 GHz: Up to 1148 Mbps
Funzionalità wireless:
– 1024-QAM
– 4× Longer OFDM Symbol
– OFDMA
– Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
– Enable/Disable Wireless Radio
– Automatic Channel Assignment
– Transmit Power Control (Adjust Transmit Power on dBm)
– QoS(WMM)
– MU-MIMO
– Seamless Roaming△
– Omada Mesh△
– Band Steering
– Load Balance
– Airtime Fairness
– Beamforming
– Rate Limit
– Reboot Schedule
– Wireless Schedule
– Wireless Statistics based on SSID/AP/Client
Sicurezza wireless:
– Captive Portal Authentication
– Access Control
– Wireless Mac Address Filtering
– Wireless Isolation Between Clients
– SSID to VLAN Mapping
– Rogue AP Detection
– 802.1X Support
– WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Potenza di trasmissione:
– CE:
<20 dBm(2.4 GHz, EIRP)
<23 dBm(5 GHz, EIRP)
– FCC:
<26 dBm (2.4 GHz)
<26 dBm (5 GHz)

GESTIONE
Omada App: Yes
Centralized Management:
– Omada Cloud-Based Controller
– Omada Hardware Controller (OC300)
– Omada Hardware Controller (OC200)
– Omada Software Controller
Cloud Access: Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Avvisi e-mail: Yes
LED ON/OFF: Yes
Management MAC Access Control: Yes
SNMP: v1, v2c, v3
Log di sistema locale e remoto: Local/Remote Syslog
SSH: Yes
Gestione web-based: HTTP/HTTPS
L3 Management: Yes
Multi-site Management: Yes
Management VLAN: Yes

ALTRO
Certificazione: CE, FCC, RoHS
Contenuto della confezione:
– EAP660 HD
– Power Adapter
– Ceiling/Wall Mounting Kits
– Installation Guide
Requisiti di sistema: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
Ambiente:
– Operating Temperature: 0–40 °C (32–104 °F)
– Storage Temperature: -40–70 °C (-40–158 °F)
– Operating Humidity: 10–90% RH non-condensing
– Storage Humidity: 5–90% RH non-condensing
