WIRELESS N150 ACCESSPOINT OUTDOOR TP-LINK CPE605 5GHZ – POE -ANT.INTEGRATE 23DBI -2T2R GARANZIA 3 ANNI-

Descrizione

WIRELESS N150 ACCESSPOINT OUTDOOR TP-LINK CPE605 5GHZ – POE -ANT.INTEGRATE 23DBI -2T2R GARANZIA 3 ANNI-

CARATTERISTICHE HARDWARE
Processore: Qualcomm 560MHz CPU, MIPS 74Kc
Memoria: 64MB DDR2 RAM,8MB Flash
Interfaccia:
– 1 10/100Mbps Shielded Ethernet Port (LAN/POE)
– 1 Reset Button
Alimentazione:
– Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
– Voltage range: 16-27VDC
Dimensioni ( L x P x A ): 350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)
Guadagno antenna: 23dBi
Ampiezza del diagramma di emissione: 7°(Azimuth), 10°(Elevation)
Sicurezza:
– 15KV ESD Protection
– 6KV Lightning Protection
Enclosure:
– Material: Outdoor PC stabilized plastic
– Weatherproof: IP65 water and dust proof design

CARATTERISTICHE WIRELESS
Standard wireless: IEEE 802.11a/n
Protocollo proprietario: TDMA Mode (with Pharos MAXtream enabled)
Velocità wireless:
– Up to 150Mbps (40MHz,Dynamic)
– Up to 72.2Mbps (20MHz,Dynamic)
– Up to 36.1Mbps (10MHz,Dynamic)
– Up to 18.05Mbps (5MHz,Dynamic)
Frequenza: 5.15~5.85GHz
Potenza di trasmissione: Max. 23dBm (Adjustable power by 1dBm)

CARATTERISTICHE SOFTWARE
IPv6: Yes
Configurazione di rete:
– WAN: Static/Dynamic/PPPoE/L2TP/PPTP
– LAN: Static/Dynamic/DHCP
– Forwarding: ALG/UPnP/Virtual Server/Port Trigger
– Security: SPI Firewall/ Ping Forbidden/DoS Protection
– Access Control
– Static Routing
– Bandwidth Control
– IP & MAC Binding
Configurazioni wireless:
– Pharos MAXtream TDMA Technology
– Selectable Channel Width: 5/10/20/40MHz
– Auto Channel Selection
– Transmit Power Control
– Dynamic Frequency Selection(DFS)
– WDS Enable/Disable
– Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
– 64/128/152-bit WEP Encryption
– SSID Broadcast Enable/Disable
– Multi-SSID with VLAN Tagging(AP Mode only)
– Distance/ACK Timeout Setting
– Wireless MAC Address Filter
– Wireless Advanced:
– Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
– Long Range PtP
Gestione:
– Discovery and Remote Management via Pharos Control application
– HTTP/HTTPS Web-based management
– System log
– SNMP Agent(v2c)
– Ping Watch Dog
– Dynamic DDNS
– SSH Server
Tool di sistema:
– Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
– Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
– Spectrum Analyzer
– Speed Test
– Ping
– Traceroute
– Antenna Alignment
Ottimizzazioni di sistema: Optimized IGMP Snooping/Proxy for multicast applications

ALTRO
Certificazione: CE, FCC, RoHS, IP65
Contenuto della confezione:
– Outdoor Wireless CPE
– 24V 0.25A Passive PoE Adapter
– Pole Mounting Kits
– AC Power Cord
– Installation Guide
Requisiti di sistema: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Ambiente:
– Operating Temperature: -40℃~70℃ (-40℉~158℉)
– Storage Temperature: -40℃~70℃ (-40℉~158℉)
– Operating Humidity: 10%~90% non-condensing
– Storage Humidity: 5%~95% non-condensing
