WIRELESS ROUTER AX1800 WI-FI 6 TP-LINK VX230V DUALBAND 1201M/5GHZ+574M/2.4GHZ-1P DSL+1P WAN+3P LAN+1P FXS-ANT.INT.

Descrizione

WIRELESS ROUTER AX1800 WI-FI 6 TP-LINK VX230V DUALBAND 1201M/5GHZ+574M/2.4GHZ-1P DSL+1P WAN+3P LAN+1P FXS-ANT.INT.

CARATTERISTICHE HARDWARE
Interfaccia:
– 3× 10/100/1000 Mbps RJ45 LAN Ports
– 1× 10/100/1000Mbps RJ45 WAN Port
– 1× DSL Port
– 1× FXS Port
– 1× USB 2.0 Port
Tasto: Power On/Off Button, Reset Button, WPS On/Off Button, Wi-Fi On/Off Button
Alimentatore esterno: 12V/2.0A
Standard IEEE: IEEE 802.3, IEEE 802.3u, 802.3ab
Standard VDSL2:
– ITU G.993.2, Up to 35b profile
– ITU-T G.993.5 (G.vector)
– ITU-T G.998.4 (G.INP)
Standard ADSL:
– Full-rate ANSI T1.413 Issue 2,
– ITU-T G.992.1(G.DMT),
– ITU-T G.992.2(G.Lite),
– ITU-T G.994.1 (G.hs),
– ITU-T G.995.1
Standard ADSL2:
– ITU-T G.992.3 (G.DMT.bis)
– ITU-T G.992.4 (G.lite.bis)
Standard ADSL2+: ITU-T G.992.5
Dimensioni ( L x P x A ): 7.9 × 5.9 × 2.7 in (199.7 x 148.6 x 67.5 mm)
Standard VOIP: SIP, up to 8 Accounts, Call Logs, Call Rules, DND & Call Blocking, Call Forwarding, Voice Mail, T.38

CARATTERISTICHE WIRELESS
Standard wireless: IEEE 802.11 ax/ac/n/a 5 GHz, IEEE 802.11 ax/b/g/n 2.4 GHz
Frequenza: 2.4 GHz and 5 GHz
Signal rate:
– 5 GHz: 1201 Mbps
– 2.4 GHz: 574 Mbps
Potenza di trasmissione:
– CE:
– <20 dBm (2.4 GHz), <23 dBm (5.15 GHz~5.35 GHz)
– <30 dBm (5.47 GHz—5.725 GHz)
Funzionalità wireless: Enable/Disable Wireless Radio, WMM, Air Time Fairness, Wireless Statistics, MAC Filtering
Sicurezza wireless: WPA/WPA2/WPA3 encryptions
Schedulazione wireless: Support 2.4 GHz and 5 GHz Wireless Schedule
Mesh Technology: EasyMesh Compatible, and support 802.11k/v/r

CARATTERISTICHE SOFTWARE
Sicurezza: IPv4/IPv6 SPI Firewall, DDoS, Service Filtering, Access Control, IP&MAC Binding
Gestione:
– Local management: WebGUI management, Aginet app management
– Remote management: TR-069, TR-098, TR-181, TR-369, TR-111,TR-143
– Cloud management: TP-Link Aginet Unified Cloud (TAUC)
DHCP: Server, Client, DHCP Client List, Address Reservation, DHCP Relay, Condition Pool
Port forwarding: Virtual Server, Port Triggering, DMZ, ALG, UPnP
Dynamic DNS: Dyn DNS, NO-IP, TP-Link DNS
VPN: OpenVPN, PPTP VPN, IPSec VPN
Protocolli: IPv4 and IPv6
Caratteristiche ATM: ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MERIPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
Funzionalità avanzate: NAT Forwarding, Address Reservation, QoS(Quality of Service), CWMP, Network Diagnosis, Traffic Statistic, Cloud upgrade, 1024-QAM, MU-MIMO, OFDMA, EasyMesh
Condivisione USB: Support Samba (Storage) / FTP Server / Media Server, 3G/4G Modem
Rete ospiti: 2.4 GHz and 5 GHz Guest Network
VPN IPsec: Support up to 16 IPSec VPN tunnels

ALTRO
Certificazione: CE
Contenuto della confezione:
– Modem Router VX230v
– RJ45 Ethernet Cable
– Power Adapter
– RJ11 Cable
– Splitter
– Quick Installation Guide
Requisiti di sistema:
– Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux
– Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled brower
Ambiente:
– Operating Temperature: 0°C40°C (32°F—104°F)
– Storage Temperature: -40°C—60°C (-40°F—140°F)
– Operating Humidity: 10%—90% non-condensing
– Storage Humidity: 5%—90% non-condensing
