WIRELESS ROUTER E GATEWAY UBIQUITI UDM-SE UNIFI DREAM MACHINE 8P RJ45 1000MB/S,1P SFP+,1P RJ45 2.5GB/S WAN,1P SFP+ WAN, 128G SS

Descrizione

WIRELESS ROUTER E GATEWAY UBIQUITI UDM-SE UNIFI DREAM MACHINE 8P RJ45 1000MB/S,1P SFP+,1P RJ45 2.5GB/S WAN,1P SFP+ WAN, 128G SS

Mechanical
Dimensions: 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″)
Weight: 4.95 kg (10.9 lb)
Enclosure materials: Aluminium CNC, SGCC steel
Mount material: SGCC steel

Hardware
Processor: Quad-core ARM® Cortex®-A57 at 1.7 GHz
System memory: 4 GB DDR4
On-board storage:
– 16 GB eMMC
– Integrated 128 GB SSD
Management interface:
– Ethernet
– Bluetooth
Networking interface:
– (8) LAN: GbE RJ45 ports
– (1) WAN: 2.5 GbE RJ45 port
SFP+ interface:
– (1) LAN: 10G SFP+
– (1) WAN: 10G SFP+
PoE interface:
– (6) PoE (Pair A 1, 2+; 3, 6-)
– (2) PoE+ (Pair A 1, 2+; 3, 6-)
IDS/IPS throughput: 3.5 Gbps
Power method:
– (1) Universal AC input, 100—240V AC, 4.4A Max., 50/60 Hz
– (1) USP-RPS DC input, 52V DC, 3.94A
Power supply: AC/DC, internal, 240W
Supported voltage range: 100—240V AC
Max. power consumption: 50W (Excluding PoE output)
Max. PoE wattage per port by PSE:
– PoE: 15.4W
– PoE+: 30W
Voltage range PoE mode:
– PoE: 44—57V
– PoE+: 50—57V
ESD/EMP protection: Air: ± 15kV, contact: ± 8kV
LCM display: (1) 1.3″ touchscreen
Button: Factory reset
Operating temperature: -10 to 40° C (14 to 104° F)
Operating humidity: 5 to 95% noncondensing
Certifications: CE, FCC, IC

LEDs
Ethernet: White: link/activity
SFP+: White: link/activity
HDD: White: disk activity, Amber: disk error
RPS: Blue: ready
